Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

Model Number : FF50

Punching cylinder : 125*30

MOQ : 1 set

Delivery Time : 30 days

Max. bending speed : 800°/sec

Max. diameter : 1500mm

Packaging Details : Wooden case

Payment Terms : L/C, T/T

Processing thickness : 2-5mm

Max. feeding speed : 55m/min

Certification : ISO9001

Brand Name : Auten

Feeding servo motor : 3kw/1 unit

Place of Origin : China

Price : Negotiable

Min. diameter : 30mm

Supply Ability : 500 sets/year

Processing width : 20-50mm

Contact Now

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

Product Application:

This equipment is engineered for the manufacture of clamps and fastening components used across various industries, including transportation, power infrastructure, and seismic restraint and bracing systems.

Product Parameter Configuration Table:

Model FF50-5
Processing width 20-50mm
Processing thickness 2-5mm
Min. diameter 30mm
Max. diameter 1500mm
Max. feeding speed 55m/min
Max. bending speed 800°/sec
Punching cylinder 125*30
Feeding servo motor 3kw/1 unit
Cut-off cylinder 150*50
Bending servo motor 3kw/1 unit
Hydraulic system Huade
Telescopic servo motor 1kw
Electrical control system Weichuang / Xinjie
Hydraulic power station motor 7.5kw
Mold Material DC53
Feed Roller Material Cr12MoV
Dimensions 2.2×1.6×1.8m

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

Technical advantages:

1. The CNC control system incorporates an intuitive operating interface and versatile control functions, simplifying machine operation, optimizing process management, and improving overall operational efficiency.

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

2. The servo-controlled positioning mechanism provides high positioning precision and accurate dimensional control, ensuring repeatable machining performance and consistent finished-product quality.

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

3. The machine supports flat steel materials in a variety of specifications and offers customized configurations to meet specific manufacturing requirements, providing flexibility for diverse production applications.

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions

Typical products include U-bolts, M-shaped clamps, seismic bracing suspension clamps, and other specialized structural fastening components.

Flat-Bar Clamping Band Machine With Intuitive CNC Interface And Versatile Control Functions
